Transportation of cars with reliability is a task. A trailer needs to have a robust structure and smart features that can handle any auto operation easily. With Infinity Trailers, the GN450 4 car hydraulic trailer, you can get many benefits, from dual loading capacity to hydraulic systems. Explore the detailed features of the GN450 with this guide.
Top Specifications and Features of the GN450 4 car Hydraulic Trailer
Dual Hydraulic Tilt Decks & Loading Capacity: The GN450 trailers have 16 ft hydraulic tilt decks, giving a combined loading capacity of 68 ft. This design ensures flexible loading designs depending on the car size.
Overall Dimension & Bed Width: This hauler has an overall length of 53 ft and a bed width of 102 in, which can haul 4 cars easily without any stress to its frame.
Structural Weight: The empty weight of the 4 car trailer is 12,000 lb, and the Gross Vehicle Weight Rating is rated at 25,000lb. This gives a good payload margin for loaded vehicles and gear.
Axles, Suspension & Brakes: GN450 is built with tandem dual 12,000 lb axles, hydraulic brakes, and utilizes a Hutch H-9700 series suspension. This ensures stable and controlled handling under heavy loads.
Hydraulic Systems & Controls: The 4 car trailerfeatures a single-acting 12-volt hydraulic pump and a 12-volt Optima battery. It powers tilt decks, ramps, and hydraulic operations.
Cylinders for Hydraulic Ramps: For upper decks, the GN450 is equipped with 4 aluminum cylinders (2.5″ × 40″), and for the hydraulic loading ramps, it includes a 2″ × 96″ cylinder. This combination allows precise and much safer lifting and tilting actions.
Lighting, Decking & Safety Features: Lighting is handled in these 4 car trailer by Optronics LED systems. Both ramps and treadways use punch-hole decking for grip and drainage. There are many additional standard safety items in this trailer, including reflector tape, a breakaway kit, and a wiring harness.
GN450 is a high-performance and feature-rich solution from Infinity trailers that delivers from every point of view you can imagine. From dual hydraulic decks and weight ratings to lighting, load management, and control systems, this stands out as a powerhouse in the car hauler market. Choose GN450 for your 4 car trailer duty today with Infinity Trailers.
