Eaton's RS safety interlock switches have been specifically designed to monitor protective guards, such as doors, flaps and hoods. All switches in this
family are safety-rated and use magnetically coded actuators to minimize defeat by simple magnets. With correct installation, the RS family complies with EN ISO 13849-1 and IEC 62061 guidelines.
Operation:
The RS safety interlock family includes three series: RS2, RS2R and RS4. The assembly comprises a sensor component and a separate magnet actuator component. The sensor is typically mounted to a stationary portion of a structure and the magnet to a movable portion. When the sensor and the actuator are within operating range, the NC contacts with be closed and the NO contacts will be open.
Features:
* Non-contact actuation
* Reversible mounting
* High misalignment tolerance
* SIL 3 and PLe ratings
* -10 °C to +55 °C temperature range
* IP67, IP69K
Benefits:
* Reduce SKUs
* Reduce installation time
* Tested to latest IEC and ISO standards
* Long life with non-contact actuation
* Wide variety of output contact configuration
* Industry standard mounting
Standards and Certifications:
* UL®, CE, cUL®, RoHS, TUV
